Raking Light
Move the pointer across the plate
A conservator walks a lamp at a grazing angle across a surface, and the relief no one could see comes up out of it — tool marks, seams, a thumbprint left in the clay. Here the lamp is your pointer. The photograph is treated as a height map, the light sits low above it, and only genuine relief answers; a flat area stays exactly the photograph it was. Move the lamp away and the plate returns to itself, byte for byte.
The workings 638 lines
<script lang="ts">
/**
* Raking Light — "examining the specimen under a conservator's grazing lamp".
*
* A museum technique: the restorer walks a light source at a shallow,
* grazing angle across a surface, and the relief of the object emerges in
* light and shadow — tool marks, seams, fingerprints, the topography paint
* normally hides. Here the lamp is the pointer: a low torch whose planar
* position tracks the cursor, raking a luminous pool across the plate while
* the rest of the photograph stays its plain, untouched self.
*
* How the relief is recovered (the demonstrable part):
* - We treat a grayscale field as a height map h(uv). Surface normals come
* from its gradient by central differences: N = normalize(-∂h, +∂h, 1/k).
* - The lamp is a point light a short height `uGrazing` above the surface at
* the cursor's planar position. Low height ⇒ near-horizontal incidence ⇒
* long shadows off every slope — the defining property of raking light.
* - Shading is Lambertian diffuse minus the *flat-surface* response, so a
* perfectly flat region keeps the photo unchanged and only genuine relief
* (deviation of N from straight-up) brightens or darkens. A tight grazing
* specular adds the characteristic glint that catches raised edges.
* - Directly under the lamp the incidence is steep (light ≈ overhead) so
* relief flattens there, exactly as a real handheld lamp behaves; the
* revealing happens in the raked ring around the hotspot.
*
* Height source, in order of preference:
* 1. `heightSrc` — a precomputed depth/height map (the same grayscale media
* variant the Living Daguerreotype uses). The correct, albedo-free path.
* 2. fallback — luminance of the colour image, lightly blurred in-shader.
* Lets the whole archive participate today; note it conflates dark paint
* with depressions, so the depth map is always preferred when present.
*
* Design contract (it must never read as a "product 3D viewer"):
* - at rest (pointer away) the canvas output is byte-for-byte the original
* photograph — the effect eases to zero, nothing lingers;
* - no chrome of its own; it fills the stage exactly like the <img> it
* replaces, so the mat / vignette / grain overlays stay as siblings;
* - graceful by construction: a plain <img> sits underneath for SSR, the
* card→detail view-transition, reduced-motion and WebGL-less browsers.
*
* Lifecycle mirrors LivingDaguerreotype: the GL context, program and geometry
* are built ONCE in onMount and persist; switching the gallery image reloads
* only the textures (via the $effect on src/heightSrc) — no recompile, no
* context-loss churn while paging ←/→.
*/
import { onMount } from 'svelte';
let {
src,
heightSrc = null,
alt = '',
intensity = 0.6,
class: className = '',
onActivate,
}: {
src?: string | null;
/** Precomputed grayscale depth/height map; falls back to colour luminance. */
heightSrc?: string | null;
alt?: string;
/** 0..1 — how strongly relief is exaggerated (scales the normal slope). */
intensity?: number;
class?: string;
onActivate?: () => void;
} = $props();
// Height of the torch above the surface plane. Small ⇒ grazing incidence.
const GRAZING = 0.2;
const EASE = 0.12; // pointer → eased lamp position
const ACT_EASE = 0.08; // effect engage / release
let host = $state<HTMLDivElement>();
let canvas = $state<HTMLCanvasElement>();
let baseImg = $state<HTMLImageElement>(); // visible <img>; reused as the GL texture source
let imageFailed = $state(false);
let glReady = $state(false); // canvas takes over from the base <img> only once it has drawn
const reducedMotion =
typeof window !== 'undefined' &&
window.matchMedia('(prefers-reduced-motion: reduce)').matches;
// ── Persistent GL state (built once, reused across image switches) ──────────
let gl: WebGLRenderingContext | null = null;
let uColor: WebGLUniformLocation | null = null;
let uHeight: WebGLUniformLocation | null = null;
let uHasHeight: WebGLUniformLocation | null = null;
let uImageAspect: WebGLUniformLocation | null = null;
let uCanvasAspect: WebGLUniformLocation | null = null;
let uMouse: WebGLUniformLocation | null = null;
let uActivation: WebGLUniformLocation | null = null;
let uTexel: WebGLUniformLocation | null = null;
let uRelief: WebGLUniformLocation | null = null;
let uGrazing: WebGLUniformLocation | null = null;
let colorTex: WebGLTexture | null = null;
let heightTex: WebGLTexture | null = null;
let hasHeight = 0;
let imageAspect = 1;
let texelX = 1 / 1024, texelY = 1 / 1024; // updated from the loaded image
// pointer → eased lamp position; activation eases the effect in/out
let targetX = 0, targetY = 0, curX = 0, curY = 0;
let targetAct = 0, curAct = 0;
let pointerInside = false;
let visible = true;
let running = false;
let raf = 0;
let hostRect: DOMRect | null = null;
let hostRectDirty = true;
let destroyed = false;
let initialized = false; // GL context + program ready
let loadedKey = ''; // de-dupes the (src|heightSrc) currently loaded/loading
let loadSeq = 0; // supersedes in-flight loads when the image changes fast
let isPointerFine = $state(true);
function handleActivate() {
if (isPointerFine) onActivate?.();
}
function updateHostRect() {
hostRect = host?.getBoundingClientRect() ?? null;
hostRectDirty = false;
}
function markHostRectDirty() {
hostRectDirty = true;
}
function stopAnimation() {
running = false;
if (raf) cancelAnimationFrame(raf);
raf = 0;
}
function reliefStrength() {
// grad samples are in 0..1; this maps intensity → a slope multiplier that
// reads as tactile relief without tipping into a plastic, embossed look.
return 8 + Math.max(0, Math.min(1, intensity)) * 28;
}
function makeTexture(): WebGLTexture | null {
if (!gl) return null;
const tex = gl.createTexture();
gl.bindTexture(gl.TEXTURE_2D, tex);
gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_WRAP_S, gl.CLAMP_TO_EDGE);
gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_WRAP_T, gl.CLAMP_TO_EDGE);
gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_MIN_FILTER, gl.LINEAR);
gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_MAG_FILTER, gl.LINEAR);
return tex;
}
function uploadImage(tex: WebGLTexture | null, img: HTMLImageElement): boolean {
if (!gl) return false;
try {
gl.bindTexture(gl.TEXTURE_2D, tex);
gl.texImage2D(gl.TEXTURE_2D, 0, gl.RGBA, gl.RGBA, gl.UNSIGNED_BYTE, img);
return true;
} catch {
return false; // cross-origin taint etc. → caller falls back
}
}
function loadImage(url: string): Promise<HTMLImageElement | null> {
return new Promise((resolve) => {
const img = new Image();
img.crossOrigin = 'anonymous';
img.onload = () => resolve(img);
img.onerror = () => resolve(null);
img.src = url;
});
}
function isSameOrigin(url: string): boolean {
try {
return new URL(url, window.location.href).origin === window.location.origin;
} catch {
return false;
}
}
// Await an existing <img> instead of refetching: only when same-origin, so
// a prod-dump URL on ritunia.com can still paint the photograph (no CORS
// on the visible <img>) while WebGL quietly sits out.
function imageMatches(img: HTMLImageElement, url: string): boolean {
try {
return img.currentSrc === url || img.src === new URL(url, window.location.href).href;
} catch {
return img.currentSrc === url || img.src === url;
}
}
function awaitImg(img: HTMLImageElement, expectedUrl: string): Promise<HTMLImageElement | null> {
if (!imageMatches(img, expectedUrl)) return Promise.resolve(null);
if (img.complete) return Promise.resolve(img.naturalWidth > 0 ? img : null);
return new Promise((resolve) => {
img.addEventListener('load', () => resolve(imageMatches(img, expectedUrl) && img.naturalWidth > 0 ? img : null), { once: true });
img.addEventListener('error', () => resolve(null), { once: true });
});
}
function resize() {
if (!host || !canvas) return;
const dpr = Math.min(window.devicePixelRatio || 1, 2);
const w = Math.max(1, Math.round(host.clientWidth * dpr));
const h = Math.max(1, Math.round(host.clientHeight * dpr));
if (canvas.width !== w || canvas.height !== h) {
canvas.width = w;
canvas.height = h;
}
}
function draw() {
if (!gl || !canvas || !colorTex) return;
resize();
gl.viewport(0, 0, canvas.width, canvas.height);
gl.clearColor(0, 0, 0, 0);
gl.clear(gl.COLOR_BUFFER_BIT);
gl.activeTexture(gl.TEXTURE0);
gl.bindTexture(gl.TEXTURE_2D, colorTex);
gl.uniform1i(uColor, 0);
gl.activeTexture(gl.TEXTURE1);
gl.bindTexture(gl.TEXTURE_2D, heightTex ?? colorTex);
gl.uniform1i(uHeight, 1);
gl.uniform1f(uHasHeight, hasHeight);
gl.uniform1f(uImageAspect, imageAspect);
gl.uniform1f(uCanvasAspect, canvas.width / canvas.height);
gl.uniform2f(uMouse, curX, curY);
gl.uniform1f(uActivation, curAct);
gl.uniform2f(uTexel, texelX, texelY);
gl.uniform1f(uRelief, reliefStrength());
gl.uniform1f(uGrazing, GRAZING);
gl.drawArrays(gl.TRIANGLE_STRIP, 0, 4);
if ((host?.clientWidth ?? 0) > 8 && (host?.clientHeight ?? 0) > 8) glReady = true;
}
function frame() {
const dx = targetX - curX;
const dy = targetY - curY;
const da = targetAct - curAct;
curX += dx * EASE;
curY += dy * EASE;
curAct += da * ACT_EASE;
draw();
// settle: once the lamp is at rest and the effect has fully released, stop
// burning frames. The final frame at curAct≈0 equals the untouched photo.
if (!pointerInside && Math.hypot(dx, dy) < 0.0006 && Math.abs(da) < 0.0015) {
curAct = targetAct; // snap to exact 0 so the last drawn frame is the plain image
draw();
running = false;
raf = 0;
return;
}
raf = requestAnimationFrame(frame);
}
function kick() {
if (running || destroyed || !colorTex) return;
if (!visible) {
draw();
return;
}
running = true;
raf = requestAnimationFrame(frame);
}
function onMove(e: PointerEvent) {
if (!host) return;
if (!hostRect || hostRectDirty) updateHostRect();
const r = hostRect;
if (!r || !r.width || !r.height) return;
targetX = ((e.clientX - r.left) / r.width) * 2 - 1;
targetY = ((e.clientY - r.top) / r.height) * 2 - 1;
pointerInside = true;
targetAct = 1;
kick();
}
function onEnter(e: PointerEvent) {
updateHostRect();
// seed the lamp at the entry point so it doesn't sweep in from the corner
onMove(e);
}
function onLeave() {
pointerInside = false;
hostRect = null;
hostRectDirty = true;
targetAct = 0; // ease the relief away → back to the plain photograph
kick();
}
// Load (or reload) the colour + optional height textures for a given pair of
// sources. Idempotent per (src|heightSrc); a newer call supersedes an older
// in-flight one via loadSeq. Reuses the persistent GL context — no teardown.
async function loadTextures(colorSrc: string, heightSrc2: string | null) {
if (!gl || destroyed) return;
const key = `${colorSrc}|${heightSrc2 ?? ''}`;
if (key === loadedKey) return;
loadedKey = key;
const seq = ++loadSeq;
glReady = false;
imageFailed = false;
const colorImg = baseImg && isSameOrigin(colorSrc)
? (await awaitImg(baseImg, colorSrc)) ?? await loadImage(colorSrc)
: await loadImage(colorSrc);
if (destroyed || seq !== loadSeq) return;
if (!colorImg) return;
imageAspect = colorImg.naturalWidth / Math.max(1, colorImg.naturalHeight);
texelX = 1 / Math.max(1, colorImg.naturalWidth);
texelY = 1 / Math.max(1, colorImg.naturalHeight);
if (!colorTex) colorTex = makeTexture();
if (!uploadImage(colorTex, colorImg)) return; // tainted → base <img> stays
hasHeight = 0;
if (heightSrc2) {
const heightImg = await loadImage(heightSrc2);
if (destroyed || seq !== loadSeq) return;
if (heightImg) {
if (!heightTex) heightTex = makeTexture();
if (uploadImage(heightTex, heightImg)) hasHeight = 1;
}
}
draw();
kick();
}
onMount(() => {
isPointerFine = window.matchMedia('(pointer: fine)').matches;
if (reducedMotion || !canvas || !host || !src) return;
// preserveDrawingBuffer: like the daguerreotype, this canvas draws then
// parks its rAF loop. Without buffer preservation the browser discards
// those pixels on a composite not preceded by a redraw (view-transition
// snapshot, the canvas's own opacity fade), leaving the stage blank until
// the next pointermove. Cheap here; correctness over a micro-optimisation.
gl =
(canvas.getContext('webgl', { alpha: true, premultipliedAlpha: false, antialias: true, preserveDrawingBuffer: true }) as WebGLRenderingContext | null) ||
(canvas.getContext('experimental-webgl', { alpha: true, preserveDrawingBuffer: true }) as WebGLRenderingContext | null);
if (!gl) return; // base <img> stays visible — silent, correct fallback
const vsrc = `
attribute vec2 aPos;
attribute vec2 aUv;
varying vec2 vUv;
void main() { vUv = aUv; gl_Position = vec4(aPos, 0.0, 1.0); }
`;
const fsrc = `
precision highp float;
varying vec2 vUv;
uniform sampler2D uColor;
uniform sampler2D uHeight;
uniform float uHasHeight;
uniform float uImageAspect;
uniform float uCanvasAspect;
uniform vec2 uMouse; // -1..1 over the stage; eased lamp position
uniform float uActivation; // 0..1 effect engagement (eased)
uniform vec2 uTexel; // 1/imgW, 1/imgH
uniform float uRelief; // normal slope multiplier
uniform float uGrazing; // lamp height above the plane (small = grazing)
float luma(vec3 c) { return dot(c, vec3(0.299, 0.587, 0.114)); }
// Height field h(uv). Depth map when present; else a lightly blurred
// luminance so the relief survives but pixel noise doesn't.
float heightAt(vec2 uv) {
if (uHasHeight > 0.5) return texture2D(uHeight, uv).r;
vec2 r = uTexel * 1.25;
float s = luma(texture2D(uColor, uv).rgb) * 0.40;
s += luma(texture2D(uColor, uv + vec2(r.x, 0.0)).rgb) * 0.15;
s += luma(texture2D(uColor, uv - vec2(r.x, 0.0)).rgb) * 0.15;
s += luma(texture2D(uColor, uv + vec2(0.0, r.y)).rgb) * 0.15;
s += luma(texture2D(uColor, uv - vec2(0.0, r.y)).rgb) * 0.15;
return s;
}
void main() {
// object-fit: contain — letterbox bands stay transparent so the
// parchment mat shows through, exactly like the <img> did.
vec2 scale = vec2(1.0);
if (uImageAspect > uCanvasAspect) scale.y = uCanvasAspect / uImageAspect;
else scale.x = uImageAspect / uCanvasAspect;
vec2 imgUv = (vUv - 0.5) / scale + 0.5;
if (imgUv.x < 0.0 || imgUv.x > 1.0 || imgUv.y < 0.0 || imgUv.y > 1.0) discard;
vec3 base = texture2D(uColor, imgUv).rgb;
// ── surface normal from the height field (central differences) ──
// Steps are a fixed texel count on each axis, so the gradient is
// isotropic in pixel space; the per-axis constant folds into uRelief.
vec2 e = uTexel * 1.5;
float hL = heightAt(imgUv - vec2(e.x, 0.0));
float hR = heightAt(imgUv + vec2(e.x, 0.0));
float hD = heightAt(imgUv - vec2(0.0, e.y));
float hU = heightAt(imgUv + vec2(0.0, e.y));
vec2 grad = vec2(hR - hL, hU - hD);
vec3 N = normalize(vec3(-grad * uRelief, 1.0));
// ── lamp: a low point light at the cursor's planar position ──
// aspect-correct image space so the luminous pool stays circular.
vec2 q = vec2(imgUv.x * uImageAspect, imgUv.y);
vec2 lUv = uMouse * 0.5 / scale + 0.5; // cursor → image uv
vec2 lq = vec2(lUv.x * uImageAspect, lUv.y);
vec2 toL = lq - q;
float dist = length(toL);
vec3 L = normalize(vec3(toL, uGrazing));
// Subtract the flat-surface response so flat regions keep the photo
// unchanged and only true relief (N tilted off vertical) modulates it.
float flatResp = L.z; // = dot(vec3(0,0,1), L)
float lambert = max(dot(N, L), 0.0);
// Tight grazing specular — the glint that catches raised edges.
vec3 V = vec3(0.0, 0.0, 1.0);
vec3 H = normalize(L + V);
float spec = pow(max(dot(N, H), 0.0), 32.0);
// Luminous pool that follows the lamp; soft, never crushing the rest.
float pool = exp(-dist * dist * 4.0);
float relief = 1.0
+ (lambert - flatResp) * (2.6 * (0.32 + pool))
+ spec * pool * 1.35;
vec3 lit = base * clamp(relief, 0.0, 4.0);
// Engage smoothly; at activation 0 the output equals the plain photo.
float k = uActivation * (0.42 + 0.58 * pool);
gl_FragColor = vec4(mix(base, lit, k), 1.0);
}
`;
function compile(type: number, source: string): WebGLShader | null {
const sh = gl!.createShader(type);
if (!sh) return null;
gl!.shaderSource(sh, source);
gl!.compileShader(sh);
if (!gl!.getShaderParameter(sh, gl!.COMPILE_STATUS)) {
gl!.deleteShader(sh);
return null;
}
return sh;
}
const vs = compile(gl.VERTEX_SHADER, vsrc);
const fs = compile(gl.FRAGMENT_SHADER, fsrc);
if (!vs || !fs) { gl = null; return; }
const prog = gl.createProgram();
if (!prog) { gl = null; return; }
gl.attachShader(prog, vs);
gl.attachShader(prog, fs);
gl.linkProgram(prog);
if (!gl.getProgramParameter(prog, gl.LINK_STATUS)) { gl = null; return; }
gl.useProgram(prog);
// ── geometry: full-frame quad. uv (0,0) = top-left, matching image rows. ──
const quad = gl.createBuffer();
gl.bindBuffer(gl.ARRAY_BUFFER, quad);
gl.bufferData(
gl.ARRAY_BUFFER,
new Float32Array([
// aPos aUv
-1, -1, 0, 1,
1, -1, 1, 1,
-1, 1, 0, 0,
1, 1, 1, 0,
]),
gl.STATIC_DRAW,
);
const aPos = gl.getAttribLocation(prog, 'aPos');
const aUv = gl.getAttribLocation(prog, 'aUv');
gl.enableVertexAttribArray(aPos);
gl.vertexAttribPointer(aPos, 2, gl.FLOAT, false, 16, 0);
gl.enableVertexAttribArray(aUv);
gl.vertexAttribPointer(aUv, 2, gl.FLOAT, false, 16, 8);
uColor = gl.getUniformLocation(prog, 'uColor');
uHeight = gl.getUniformLocation(prog, 'uHeight');
uHasHeight = gl.getUniformLocation(prog, 'uHasHeight');
uImageAspect = gl.getUniformLocation(prog, 'uImageAspect');
uCanvasAspect = gl.getUniformLocation(prog, 'uCanvasAspect');
uMouse = gl.getUniformLocation(prog, 'uMouse');
uActivation = gl.getUniformLocation(prog, 'uActivation');
uTexel = gl.getUniformLocation(prog, 'uTexel');
uRelief = gl.getUniformLocation(prog, 'uRelief');
uGrazing = gl.getUniformLocation(prog, 'uGrazing');
gl.enable(gl.BLEND);
gl.blendFunc(gl.SRC_ALPHA, gl.ONE_MINUS_SRC_ALPHA);
function handleContextLost(e: Event) {
e.preventDefault();
stopAnimation();
glReady = false;
initialized = false;
loadedKey = '';
colorTex = null;
heightTex = null;
gl = null;
}
function handleContextRestored() {
glReady = false; // a full remount recreates context + program
}
// After a view transition the live canvas can hold a stale/blank buffer
// until something forces a fresh draw; the layout fires this once the
// transition settles so the plate redraws without user input.
function onExternalRedraw() {
markHostRectDirty();
draw();
kick();
}
window.addEventListener('gotiga:redraw', onExternalRedraw);
canvas.addEventListener('webglcontextlost', handleContextLost);
canvas.addEventListener('webglcontextrestored', handleContextRestored);
host.addEventListener('pointerenter', onEnter);
host.addEventListener('pointermove', onMove);
host.addEventListener('pointerleave', onLeave);
const scrollOptions = { passive: true, capture: true } as const;
window.addEventListener('scroll', markHostRectDirty, scrollOptions);
window.addEventListener('resize', markHostRectDirty);
const io = new IntersectionObserver(
([entry]) => {
visible = entry.isIntersecting;
if (visible) { markHostRectDirty(); kick(); }
},
{ threshold: 0 },
);
io.observe(host);
const ro = new ResizeObserver(() => {
markHostRectDirty();
kick();
});
ro.observe(host);
initialized = true;
loadTextures(src, heightSrc);
return () => {
destroyed = true;
stopAnimation();
window.removeEventListener('gotiga:redraw', onExternalRedraw);
canvas?.removeEventListener('webglcontextlost', handleContextLost);
canvas?.removeEventListener('webglcontextrestored', handleContextRestored);
host?.removeEventListener('pointerenter', onEnter);
host?.removeEventListener('pointermove', onMove);
host?.removeEventListener('pointerleave', onLeave);
window.removeEventListener('scroll', markHostRectDirty, scrollOptions);
window.removeEventListener('resize', markHostRectDirty);
io.disconnect();
ro.disconnect();
const ext = gl?.getExtension('WEBGL_lose_context');
ext?.loseContext();
gl = null;
};
});
// Reload only the textures when the gallery image (or its height map) changes —
// context, program and geometry are untouched. Guarded so the initial mount
// (handled in onMount) isn't loaded twice.
$effect(() => {
const s = src;
const h = heightSrc;
if (initialized && s) loadTextures(s, h);
});
$effect(() => {
intensity;
if (initialized && colorTex) { draw(); kick(); }
});
</script>
<div
bind:this={host}
class="raking {className}"
class:raking--zoomable={isPointerFine && !!onActivate}
role={isPointerFine && onActivate ? 'button' : 'img'}
tabindex={isPointerFine && onActivate ? 0 : undefined}
aria-label={alt}
onclick={handleActivate}
onkeydown={(e) => { if (e.key === 'Enter' || e.key === ' ') { e.preventDefault(); handleActivate(); } }}
>
<!-- Base photograph: always present. No crossorigin — a failed CORS check
on the visible <img> is a broken-image icon, not a quiet GL fallback. -->
{#if src && !imageFailed}
<img bind:this={baseImg} class="raking-base" {src} {alt}
draggable="false"
onerror={() => (imageFailed = true)} />
{:else}
<div class="raking-fallback" aria-hidden="true"></div>
{/if}
<canvas bind:this={canvas} class="raking-canvas" class:is-ready={glReady} aria-hidden="true"></canvas>
</div>
<style>
.raking {
position: relative;
width: 100%;
height: 100%;
overflow: hidden;
}
.raking--zoomable {
cursor: zoom-in;
}
.raking-base,
.raking-canvas {
position: absolute;
inset: 0;
width: 100%;
height: 100%;
}
.raking-base {
object-fit: contain;
user-select: none;
-webkit-user-drag: none;
}
.raking-canvas {
opacity: 0;
transition: opacity 0.4s ease;
pointer-events: none;
}
.raking-canvas.is-ready {
opacity: 1;
}
.raking-fallback {
width: 100%;
height: 100%;
background:
radial-gradient(circle at 50% 28%, rgba(255, 255, 255, 0.5), transparent 48%),
rgba(244, 236, 222, 0.75);
}
</style>
